ADLA - dbt

Incremental data transformation for ADLA using dbt to get data into Delta Lake tables.

dbt Docs · Azure Data Lake Analytics docs · Delta Lake

---

What is this?

This is an opinionated dbt adapter that makes it easier to test and schedule ADLA via dbt CLI without requiring an external orchestrator (such as Data Factory) to get non-Delta Lake source data lightly-transformed with SQL and incrementally ingestied via ADLA compute into Delta Lake Tables using quasi ANSI-SQL syntax.

The adapter handles performing non-SQL syntax generation at compile time in the dbt adapter using dbt macros.

As a result of this conscious design decision, the adapter does not encourage working with non-SQL constructs such as pre-processing imperative directives like #FOO.

In fact, in the future, the adapter can/will use sqlglot to block non-SQL syntax in the model SQL like #FOO, the goal here is to keep the business logic as close to ANSI-SQL as possible for portability across engines. As a result of this, a tradeoff is the ADLA feature surface is limited in this dbt adapter to only support run-time syntax, not ADLA compile-time syntax such as #FOO or #IFDEF etc.

Key features

• Clean SQL models — write SELECT ... FROM @data; macros generate #DECLARE, EXTRACT, INSERT INTO
• Microbatch incremental — append-only by default; opt into idempotent DELETE+INSERT per partition with delete_before_insert: true. dbt retry/backfill built in
• Batch bin-packing — days_per_batch groups multiple days into a single SCOPE job to reduce ADLA overhead
• High-watermark skip — queries MAX(partition_col) from Delta via DuckDB and skips already-processed batches
• Smart WHERE injection — models with an existing WHERE clause get date filters merged with AND, not duplicated
• Declarative table properties — compression, checkpoint intervals via scope_settings

How it works

SS files live on ADLS in date-partitioned directories. dbt run generates a SCOPE script per batch and submits each as an ADLA job. Each job reads only its date range (FileSet partition elimination), optionally deletes the target partition in Delta (when delete_before_insert: true), and inserts into a Delta table on ADLS.

How dbt picks which batches to run

The adapter detects existing Delta tables by checking ADLS for _delta_log/ directories. This tells dbt-core whether a model is running for the first time or incrementally:

Scenario	What runs
First run or --full-refresh	Every batch from begin (model config) through today
Incremental run (table exists)	Only the lookback most recent batches (default: yesterday + today)
Manual backfill	Exactly the range you pass via --event-time-start / --event-time-end

The lookback parameter (default 1) controls how many recent batches to reprocess on each incremental run, catching late-arriving SS files. For gap recovery (e.g. backfilling a missed week), use the CLI flags.

High-watermark skip — on each incremental run the adapter queries MAX(partition_col) from the Delta transaction log via DuckDB (no ADLA compute). Batches whose partition value is ≤ the high watermark are emitted as no-ops, avoiding redundant SCOPE jobs. The result is cached once per dbt run invocation.

What each SCOPE job does

flowchart TB
    subgraph dbt["dbt-core — microbatch orchestrator"]
        direction TB
        Detect["Adapter checks ADLS<br/><i>_delta_log/ exists?</i>"]
        Config["Model config<br/><i>begin, lookback, batch_size</i>"]
        BatchCalc["Compute pending batches<br/>first run: begin → today<br/>incremental: lookback window"]
        Detect --> BatchCalc
        Config --> BatchCalc
    end

    subgraph ADLA["ADLA — runs one SCOPE script per batch"]
        direction TB
        S1["SET @@FeaturePreviews<br/>#DECLARE @startDate, @endDate"]
        DDL["CREATE TABLE IF NOT EXISTS<br/>PARTITIONED BY event_year_date<br/>OPTIONS LAYOUT = DELTA"]
        DEL["DELETE FROM @target<br/>WHERE partition in batch range<br/><i>only if delete_before_insert</i>"]
        EXT["📖 EXTRACT FROM SS files<br/>WHERE _date in batch range<br/>→ @data rowset"]
        TX["🔀 SQL Transform — your dbt model (.sql)<br/>SELECT …, _date.ToString(…) AS partition_col<br/>FROM @data → @batch_data"]
        INS["💾 INSERT INTO @target<br/>SELECT * FROM @batch_data"]
        S1 --> DDL --> DEL --> EXT --> TX --> INS
    end

    subgraph Storage["Azure Data Lake Storage"]
        direction LR
        subgraph Sources["Gen1 — SS source files"]
            direction TB
            SS1["📂 /2026/04/01/<br/>20260401_*.ss"]
            SS2["📂 /2026/04/02/<br/>20260402_*.ss"]
            SS3["📂 /2026/04/03/<br/>20260403_*.ss"]
        end
        subgraph Target["Gen2 — Delta Lake table"]
            direction TB
            P1["📂 event_year_date=20260401/<br/>part-*.parquet"]
            P2["📂 event_year_date=20260402/<br/>part-*.parquet"]
            DL["📄 _delta_log/"]
        end
    end

    BatchCalc -- "one SCOPE script per batch<br/>(REST API submit + poll)" --> ADLA
    EXT -. "reads SS files" .-> Sources
    INS -- "writes partitions" --> Target

    style DEL fill:#fee,stroke:#c00
    style TX fill:#e8e0f8,stroke:#6a3cbc
    style Detect fill:#e8f4e8,stroke:#2a2

Loading

On full refresh, every batch from begin to today runs and there is no DELETE step. On incremental, only the lookback window runs. The DELETE step (red) is opt-in via delete_before_insert: true — when enabled, re-running the same date range replaces the partition rather than creating duplicates. When omitted (default), batches are append-only. Table detection (green) checks ADLS for _delta_log/ to determine if the model should run incrementally. Batches already present in Delta (per the high-watermark check) are skipped automatically.

The scope jobs end up looking like this in ADLA:

Install

curl -LsSf https://astral.sh/uv/install.sh | sh  # one-time install for uv
uv sync --extra dev                               # creates .venv and installs dbt-scope + dev deps

Configure

All sensitive values live in .env (see .env.example). The profile references them via env_var():

# profiles.yml
my_project:
  target: dev
  outputs:
    dev:
      type: scope
      database: "{{ env_var('SCOPE_STORAGE_ACCOUNT') }}"
      schema: "{{ env_var('SCOPE_CONTAINER') }}"
      adla_account: "{{ env_var('SCOPE_ADLA_ACCOUNT') }}"
      storage_account: "{{ env_var('SCOPE_STORAGE_ACCOUNT') }}"
      container: "{{ env_var('SCOPE_CONTAINER') }}"
      delta_base_path: delta
      au: 100
      priority: 1

dbt concept	SCOPE concept
database	Storage account name
schema	ADLS container
table	Full-refresh: CREATE TABLE + INSERT INTO
incremental	Microbatch: INSERT (append); opt-in DELETE+INSERT via delete_before_insert
model SQL	SELECT from @data (extracted SS rowset)

Usage

Full refresh

{{ config(
    materialized='table',
    delta_location='abfss://ctr@acct.dfs.core.windows.net/delta/my_table',
    ss_source_path='/my/cosmos/path/to/MyStream',
    partition_by='event_year_date',
    scope_columns=[
        {'name': 'server_name', 'type': 'string'},
        {'name': 'event_year_date', 'type': 'string'}
    ],
    scope_settings={
        'microsoft.scope.compression': 'vorder:zstd#11',
        'delta.checkpointInterval': 5
    }
) }}

SELECT logical_server_name_DT_String AS server_name,
       _date.ToString("yyyyMMdd") AS event_year_date
FROM @data

Incremental (microbatch) — append-only

{{ config(
    materialized='incremental',
    incremental_strategy='microbatch',
    event_time='event_year_date',
    batch_size='day',
    begin='2026-04-01',
    lookback=1,
    partition_by='event_year_date',
    delta_location='abfss://ctr@acct.dfs.core.windows.net/delta/my_model',
    ss_source_path='/my/cosmos/path/to/MyStream',
    days_per_batch=15,
    scope_columns=[
        {'name': 'server_name', 'type': 'string'},
        {'name': 'event_year_date', 'type': 'string'}
    ]
) }}

SELECT logical_server_name_DT_String AS server_name,
       _date.ToString("yyyyMMdd") AS event_year_date
FROM @data

Incremental (microbatch) — idempotent delete+insert

Add delete_before_insert: true to DELETE the partition range before INSERT, making re-runs safe against duplicates:

{{ config(
    materialized='incremental',
    incremental_strategy='microbatch',
    event_time='event_year_date',
    batch_size='day',
    begin='2026-04-01',
    lookback=1,
    partition_by='event_year_date',
    delta_location='abfss://ctr@acct.dfs.core.windows.net/delta/my_model',
    ss_source_path='/my/cosmos/path/to/MyStream',
    delete_before_insert=true,
    days_per_batch=15,
    scope_columns=[
        {'name': 'server_name', 'type': 'string'},
        {'name': 'event_year_date', 'type': 'string'}
    ]
) }}

SELECT logical_server_name_DT_String AS server_name,
       _date.ToString("yyyyMMdd") AS event_year_date
FROM @data

Incremental with a filter

Models that already have a WHERE clause work seamlessly — the adapter uses sqlglot to detect the existing WHERE and merges the batch date filter with AND:

{{ config(
    materialized='incremental',
    incremental_strategy='microbatch',
    event_time='event_year_date',
    batch_size='day',
    begin='2026-04-01',
    lookback=1,
    partition_by=['event_year_date', 'edition'],
    delta_location='abfss://ctr@acct.dfs.core.windows.net/delta/my_filtered_model',
    ss_source_path='/my/cosmos/path/to/MyStream',
    scope_columns=[
        {'name': 'server_name', 'type': 'string'},
        {'name': 'edition', 'type': 'string'},
        {'name': 'event_year_date', 'type': 'string'}
    ]
) }}

SELECT logical_server_name_DT_String AS server_name,
       edition,
       _date.ToString("yyyyMMdd") AS event_year_date
FROM @data
WHERE edition == "Standard"

Incremental config reference

Config	Default	Description
delete_before_insert	false	DELETE the partition range before INSERT for idempotent re-runs
days_per_batch	1	Days per SCOPE job. 15 → a 30-day backlog produces 2 jobs instead of 30
partition_by	—	Single column name or list of columns. First column drives date partitioning
lookback	1	How many recent batches to reprocess, catching late-arriving SS files

dbt retry re-runs failed batches. dbt run --event-time-start/end backfills a range.

Contributing

See CONTRIBUTING.md.
